Influence of Nanofluid Types on the Enhancements of Solar Collector Performance
DOI:
https://doi.org/10.61856/f7m6ty09Keywords:
Solar Energy Experiment Investigation Efficiency Types of Nanoparticles Output PowerAbstract
Nowadays, solar energy is attracting a great deal of research interest. Optimizing solar collectors by incorporating nanoparticles into the base fluid is one area of current research focus. This study investigates how the types of nanoparticles affect the performance of solar collector. We investigated the effects of various nanoparticles types on performance of solar collector. Nanofluid 1 (alumina nanoparticles; Al2O3) and nanofluid 2 (silicon dioxide nanoparticles; SiO2) were combined with water. Nanofluids are made with a constant nanoparticle concentration of 0.5 vol. %. Data collection was conducted under Iraqi environments during the three-month study period (January, February, and March) from 9 a.m. to 3 p.m. In particular, the data for every two-hour period is displayed. The results demonstrated the collector’s efficiency significantly influenced by nanoparticles’ type. At 1 p.m. in February, nanofluid 1 was 4.8% in front of nanofluid 2. The significance of nanoparticle materials in enhancing solar collector efficiency is highlighted by this outcome. When water-based fluid in the solar collector was compared to nanofluids 2 and 1, the latter demonstrated a typically better efficiency. Nanoparticle owns higher thermal conductivity which is one of the reasons behind the increments of the nanofluid's overall conductivity.
References
Azeez, K., Their, K. M., & Ibrahim, Z. A. (2022). Evaluation of flat plate solar heater filling in nanofluid under climatic of Iraq conditions. Case Studies in Thermal Engineering, 39, 102447. https://doi.org/10.1016/j.csite.2022.102447
Choi, S. U., & Eastman, J. A. (1995). Enhancing thermal conductivity of fluids with nanoparticles (No. ANL/MSD/CP-84938; CONF-951135-29). Argonne National Lab.(ANL), Argonne, IL (United States).
Duffie, J. A., & Beckman, W. A. (2013). Solar engineering of thermal processes. John Wiley & Sons. https://doi.org/10.1002/9781118671603
Gupta, M., Singh, V., Kumar, R. and Said, Z., 2017. A review on thermophysical properties of nanofluids and heat transfer applications. Renewable and Sustainable Energy Reviews, 74, pp.638-670. https://doi.org/10.1016/j.rser.2017.02.073
Hussein, A. M., Kadirgama, K., & Noor, M. M. (2017). Nanoparticles suspended in ethylene glycol thermal properties and applications: An overview. Renewable and Sustainable Energy Reviews, 69, 1324-1330. https://doi.org/10.1016/j.rser.2016.12.047
Hwang, K. S., Jang, S. P., & Choi, S. U. (2009). Flow and convective heat transfer characteristics of water-based Al2O3 nanofluids in fully developed laminar flow regime. International journal of heat and mass transfer, 52(1-2), 193-199. https://doi.org/10.1016/j.ijheatmasstransfer.2008.06.032
Javadi, F. S., Sadeghipour, S., Saidur, R., BoroumandJazi, G., Rahmati, B., Elias, M. M., & Sohel, M. R. (2013). The effects of nanofluid on thermophysical properties and heat transfer characteristics of a plate heat exchanger. International Communications in Heat and Mass Transfer, 44, 58-63. https://doi.org/10.1016/j.icheatmasstransfer.2013.03.017
Khalid, S., Zakaria, I. A., & Wan Mohamed, W. A. N. (2019). Comparative analysis of thermophysical properties of Al2O3 and SiO2 nanofluids. Journal of Mechanical Engineering (JMechE), (1), 153-163.
Mathew, N., Jejurkar, A. N., & Nair, P. S. (2021). A REVIEW ON EXISTING SOLAR DISTILLATION SYSTEMS.
Ramachandran, K., Hussein, A. M., Kadirgama, K., Ramasamy, D., Azmi, W. H., Tarlochan, F., & Kadirgama, G. (2017). Thermophysical properties measurement of nano cellulose in ethylene glycol/water. Applied Thermal Engineering, 123, 1158-1165. https://doi.org/10.1016/j.applthermaleng.2017.05.067
Said, Z., Sabiha, M. A., Saidur, R., Hepbasli, A., Rahim, N. A., Mekhilef, S., & Ward, T. A. (2015). Performance enhancement of a flat plate solar collector using titanium dioxide nanofluid and polyethylene glycol dispersant. Journal of Cleaner Production, 92, 343-353. https://doi.org/10.1016/j.jclepro.2015.01.007
Said, Z., Sajid, M. H., Alim, M. A., Saidur, R., & Rahim, N. A. (2013). Experimental investigation of the thermophysical properties of AL2O3-nanofluid and its effect on a flat plate solar collector. International communications in heat and mass transfer, 48, 99-107. https://doi.org/10.1016/j.icheatmasstransfer.2013.09.005
Sundar, L. S., Ramana, E. V., Said, Z., Punnaiah, V., Mouli, K. V. C., & Sousa, A. C. (2020). Properties, heat transfer, energy efficiency and environmental emissions analysis of flat plate solar collector using nanodiamond nanofluids. Diamond and Related Materials, 110, 108115. https://doi.org/10.1016/j.diamond.2020.108115
Terekhov, V. I., Kalinina, S. V., & Lemanov, V. V. (2010). The mechanism of heat transfer in nanofluids: state of the art (review). Part 2. Convective heat transfer. Thermophysics and Aeromechanics, 17, 157-171. https://doi.org/10.1134/S0869864310020010
Xie, H., Lee, H., Youn, W., & Choi, M. (2003). Nanofluids containing multiwalled carbon nanotubes and their enhanced thermal conductivities. Journal of Applied physics, 94(8), 4967-4971. https://doi.org/10.1063/1.1613374
Yu, G., Yang, H., Luo, D., Cheng, X., & Ansah, M. K. (2021). A review on developments and researches of building integrated photovoltaic (BIPV) windows and shading blinds. Renewable and Sustainable Energy Reviews, 149, 111355. https://doi.org/10.1016/j.rser.2021.111355
Zhang, X., Gu, H., & Fujii, M. (2007). Effective thermal conductivity and thermal diffusivity of nanofluids containing spherical and cylindrical nanoparticles. Experimental Thermal and Fluid Science, 31(6), 593-599. https://doi.org/10.1016/j.expthermflusci.2006.06.009
